    15 inch G150XJE-E01 IPS 1024*768 Chimei LCD Display Panel with 70K LED Lifetime for Industrial Application

    Ask Lasest Price
    Brand Name : INNOLUX
    Model Number : G150XJE-E01
    Certification : ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
    Price : Please contact us for latest price
    Delivery Time : 1~7 working days
    Payment Terms : T/T, L/C, Credit card, PayPal
    Supply Ability : 500,0 pieces per day
    • Product Details
    • Company Profile

    15 inch G150XJE-E01 IPS 1024*768 Chimei LCD Display Panel with 70K LED Lifetime for Industrial Application

    Product Description:

    Chimei Innolux G150XJE-E01 Application Details
    Basic Detail :Panel BrandINNOLUX/CHI MEIModel NameG150XJE-E01
    Panel Typea-Si TFT-LCD , LCMAnother Name
    Panel Size15”Designed ForIndustrial,Automotive Display,Gaming
    Maximum Ratings :OP Temperature-20 ~ 70 °CST Temperature-30 ~ 70 °C
    RoHSRoHSVibration Level-
    Features :WLED Backlight,Life>=70K hours,With LED Driver,6/8bit,Matte
    Chimei Innolux G150XJE-E01 Optical Details
    Basic Information :Luminance400 cd/m²(Typ.)Contrast Ratio2500:1 (Typ.) (Transmissive)
    Good View atSymmetryResponse Speed16/7 (Typ.)(Tr/Td) ms
    Viewing Angle88/88/88/88(Typ.)(CR≥10)Operating ModeNPVA, Normally Black, Transmissive
    Color Performance :ChromaticityWx:0.313; Wy:0.329Display Colors262K/16.7M (6-bit / 8-bit)
    Color Temperature6485KWhite Variation1.25/1.33 (Typ./Max.)(9 points)
    1931 Color Gamlt :NTSC Ratio72%sRGB92% coverage
    Adobe RGB71% coverageDCI-P374% coverage
    Rec.202054% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    Chimei Innolux G150XJE-E01 Mechanical Details
    Pixel Features :Number of Pixel1024(RGB)*768, XGAArrangementRGB Vertical Stripe
    Dot Pitch0.099*0.297 mm (H*V)Pixel Pitch (W*H)0.297*0.297 mm (H*V) [85PPI]
    Physical Size :Active Viewing(mm)304.128*228.096 mm (H*V)Bezel Area (mm)307.4*231.3 mm (H*V)
    Outline Dim.(mm)326.5*253.5 mm (H*V)Depth(mm)9.0/9.6 (Typ./Max.)
    Outline Features :Form StyleFlat RectangleOutline Shape
    Aspect Ratio4:3 (W:H)OrientationLandscape type
    Fixation :Side mounting holes (4-M3) on left, right bezel
    Other Spec :Weight942/980g (Typ./Max.)SurfaceAntiglare, Hard coating (3H)


    Features:

    INNOLUX LCD Display is a product offered by display panel manufacturers for industrial display panel applications.

    The viewing direction of this LCD display is IPS or In-Plane Switching. This technology provides a wider viewing angle and better color reproduction compared to other display technologies. It also has a viewing angle of 88/88/88/88 (RLUD), which ensures that the display remains visible from different angles.

    The luminance of the INNOLUX LCD Display is 400 nits. This means that the display is bright enough to be viewed in different lighting conditions, making it suitable for both indoor and outdoor use. The resolution of the display is 1024*768, which is perfect for displaying clear and detailed images and videos.

    In terms of storage temperature, the INNOLUX LCD Display can withstand temperatures ranging from -30℃ to 70℃. This makes it suitable for use in different environments, including harsh conditions.

    Overall, the INNOLUX LCD Display is a reliable and high-quality display panel that is perfect for various applications. Whether you need it for medical tft display, military lcd systems, or industrial automation, this display panel will provide excellent performance and durability.

    Applications:

    One of the key features of the G150XJE-E01 is its high luminance of 400 nits, which makes it perfect for use in bright environments. It also has a wide viewing angle of 88/88/88/88 degrees, ensuring that it can be seen clearly from almost any direction. The interface is EDP 30, allowing for easy connectivity with other devices.

    Thanks to its durability and reliability, the INNOLUX G150XJE-E01 is perfect for use in a range of industrial settings. It can be used as a vehicle LCD display, for example, where it can withstand the rigors of constant movement and vibration. It is also suitable for use in manufacturing environments, where it can be exposed to dust, dirt and other contaminants without suffering any damage.


    Support and Services:

    At INNOLUX, we provide comprehensive technical support and services for our LCD Display products to ensure optimal performance and customer satisfaction. Our services include:

    • Product training and consultation
    • Installation and configuration assistance
    • On-site technical support
    • Remote technical support
    • Repair and maintenance services
    • Upgrades and customization options

    Our team of experienced technicians and engineers are dedicated to providing timely and effective solutions to any technical issues that may arise with our LCD Display products. We are committed to delivering high-quality products and services that meet the needs of our customers.

    Packing and Shipping:

    Product Packaging:

    • The INNOLUX LCD Display will be securely packaged in a foam-lined cardboard box.
    • Accessories such as cables and user manuals will be included in the package.
    • The box will be labeled with the product name, model number, and handling instructions.

    Shipping:

    • The package will be shipped via a reliable courier service.
    • Shipping costs will be calculated based on the destination and shipping speed chosen.
    • The customer will receive a tracking number once the package has been shipped.
    • Delivery times may vary depending on the destination and shipping speed chosen.
