    G101ICE-LH1 IPS LCD Display High Brightness INNOLUX LCD Panel

    Ask Lasest Price
    Brand Name : INNOLUX
    Model Number : G101ICE-LH1
    Certification : ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
    Price : Please contact us for latest price
    Delivery Time : 1~7 working days
    Payment Terms : T/T, L/C, Credit card, PayPal
    Supply Ability : 500,0 pieces per day
    • Product Details
    • Company Profile

    G101ICE-LH1 IPS LCD Display High Brightness INNOLUX LCD Panel

    G101ICE-LH1 IPS LCD Display with Wide Temperature Range High Brightness Innolux Panel

    Product Description:

    Innolux G101ICE-LH1 Mechanical Details
    Pixel Features :Resolution1280(RGB)×800 [WXGA]Dot Pitch(mm)0.0565×0.1695 mm
    Pixel FormatRGB Vertical StripePixel Pitch(mm)0.1695×0.1695 mm [149PPI]
    Mechanical Size :Active Area(mm)216.96(W)×135.6(H) mmOverall Dim.230.7(W)×152.55(H) mm
    Bezel Opening218.96(W)×137.6(H) mmDepth(mm)6.5±0.5 mm
    Outline Features :Form StyleFlat RectangleOutline Shape
    Aspect Ratio16:10 (H:V)OrientationLandscape type
    Holes & Brackets :Side mounting holes (4-M2) on left, right bezel
    Other Spec :Weight300/315g (Typ./Max.)TreatmentAntiglare, Hard coating (3H)
    Innolux G101ICE-LH1 Optical Details
    Basic Information :Luminance(cd/m²)500 (Typ.)Contrast Ratio800:1 (Typ.) (Transmissive)
    Viewing Angle88/88/88/88 (Typ.)(CR≥10)Display ModeAAS, Normally Black, Transmissive
    Best View onSymmetryResponse(ms)13/12 (Typ.)(Tr/Td) (ms)
    Color Performance :White CoordinateWx:0.313; Wy:0.329Display Colors262K/16.7M (6-bit / 8-bit)
    Color Temperature6485KWhite Uniformity1.43 (Max.)(5 points)
    1931 Color Gamut :NTSC Ratio73%sRGB96% coverage
    Adobe RGB74% coverageDCI-P376% coverage
    Rec.202055% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

    Features:

    • Product Name: INNOLUX LCD Display
    • Wide Viewing Direction: IPS
    • LVDS display
    • High Resolution lcd
    • Type: TFT Module
    • Application: Vehicle LCD Display, Industrial TFT

    The INNOLUX LCD Display is made by a reputable LCD display manufacturer, and you can rest assured that you're getting a quality product. This display is designed for use in industrial display panels, making it perfect for use in a variety of settings. Whether you're using it in a factory, warehouse, or any other industrial setting, this display is sure to meet your needs.

    This display also features an edp display interface, which allows for high-speed data transfer between the display and other devices. This is perfect for those who need a display that can keep up with their demands. With this display, you'll be able to get the job done quickly and efficiently.


    Applications:

    The INNOLUX G101ICE-LH1 has a size of 10.1 inches and a viewing angle of 88/88/88/88 (RLUD). The contrast ratio of this display is 800, and it has a long LED lifetime of 50,000 hours. The outline dimension of this display panel is 230.7 x 152.55 x 6.5 mm.

    The G101ICE-LH1 is an ideal medical TFT display panel because it has been certified to meet various medical standards. It is perfect for use in medical instruments where a high-quality display module is necessary.

    If you are looking for a reliable INNOLUX display panel, the G101ICE-LH1 is a great choice. It is a high-quality TFT LCD module that is perfect for a range of applications, including medical instruments.


    Support and Services:

    Our INNOLUX LCD Display product comes with comprehensive technical support and services to ensure optimal performance and customer satisfaction. Our technical support team is available to assist with any inquiries related to the product's installation, operation, and troubleshooting. In addition, we offer firmware updates and software customization services to meet the unique needs of our customers.

    Our services also include quality control and testing, as well as product certification to ensure compliance with industry standards and regulations. We provide reliable logistics and shipping services to ensure prompt delivery of our products to our customers worldwide. Our customer service team is available to assist with any inquiries related to order placement, delivery, and after-sales support.

    Packing and Shipping:

    Product Packaging:

    The INNOLUX LCD Display product is packaged in a sturdy cardboard box with foam inserts to protect the display during shipping. The box is labeled with the product name and specifications for easy identification.

    Shipping:

    The INNOLUX LCD Display product is shipped using a reputable courier service such as FedEx or DHL. The product is insured during shipping to protect against any damage that may occur. Customers will receive a tracking number upon shipment so they can track the delivery status of their order.



    Innolux G101ICE-LH1 Carton Details
    Box TypePcs/BoxPackage LWH (mm)G.W (kgs)
    28435×350×27512.02
