21.5 inch G215HAN01.3 AUO 1920x1080 LVDS Display Panel for Industrial Display Monitors

Product Description:

The AUO Flat Panel Display is a top-of-the-line product that delivers exceptional performance and features. Its IPS display panel offers stunning visuals in full HD resolution, and its high luminance of 250 nits ensures that your content is visible even in bright environments. With an outline dimension of 497.6×292.2×11, this display panel is perfect for applications that require an immersive visual experience. Additionally, its ability to withstand extreme temperatures makes it ideal for use in harsh environments.

Features:

• Auo display panel
• TFT panel display
• High resolution display
• Industrial display
• Medical grade display
• This product features an IPS panel, making it an IPS display panel.

Technical Parameters:

AUO G215HAN01.3 Optical Details
Basic Information :	Luminance	250cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	12/10(Typ.)(Tr/Td)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Operating Mode	AHVA, Normally Black, Transmissive
Color Performance :	Chromaticity	X:0.313; Y:0.329	Support Color	16.7M (6-bit + Hi-FRC)
	Color Temperature	6485K	White Variation	1.18/1.25 (Typ./Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	75%	sRGB	97% coverage
	Adobe RGB	76% coverage	DCI-P3	78% coverage
	Rec.2020	56% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
AUO G215HAN01.3 Mechanical Details
Pixel Features :	Number of Pixel	1920(RGB)*1080, FHD	Arrangement	RGB Vertical Stripe
	Dot Pitch(W*H)	0.08265*0.24795 mm (H*V)	Pixel Pitch(mm)	0.24795*0.24795 mm (H*V) [102PPI]
Physical Size :	Active Viewing(mm)	476.064*267.786 mm (H*V)	Outline Dim.(mm)	497.6*292.2 mm (H*V)
	Bezel Area (mm)	479.8*271.3 mm (H*V)	Outline Depth	11.0 (Max.) mm
Outline Features :	Form Style	Flat Rectangle	Outline Shape
	Aspect Ratio	16:9(H:V)	Orientation	Landscape type
Holes & Brackets :	Side mounting holes (4-M3) on left, right bezel
Other Features :	Weight	1.74Kgs (Typ.)	Surface	Antiglare, Hard coating (3H)

Applications:

This new LCD panel is perfect for applications that require stunning visuals, such as digital signage, gaming, and medical imaging.

Whether you need a display panel for medical equipment, industrial control systems, or gaming monitors, the G215HAN01.3 model is a versatile choice. With a wide viewing angle of 89/89/89/89 and a large active area of 476.064×267.786, this panel delivers vivid and clear images.

The G215HAN01.3 model is also designed for durability and ease of use. It can operate in a range of temperatures, from -20℃ to 60℃ for storage and -0℃ to 60℃ for operation. With a luminance of 250 nits, it is suitable for use in a variety of lighting conditions.

Support and Services:

Our AUO Display Panel products come with comprehensive technical support and services to ensure that you have a seamless experience. Our product technical support includes:

• Expert technical assistance in resolving any issues or queries related to the product
• Access to online resources such as user manuals, software downloads, and FAQs
• Diagnostic tools to help identify and troubleshoot any problems
• Regular software updates to ensure optimal performance

In addition to technical support, we also offer a range of services to help you get the most out of your product, including:

• Professional installation services
• Product training and education
• Customized solutions to meet your specific needs
• Extended warranties for added peace of mind

Our goal is to provide you with the best possible experience with our AUO Display Panel products, and our technical support and services are designed to do just that.

Packing and Shipping:

Product Packaging:

• The AUO display panel is carefully packed to ensure safe transit.
• The panel is placed in a specially designed box with protective foam padding.
• The box is sealed securely to prevent any damage during shipping.

Shipping:

• The AUO display panel is shipped via trusted courier services.
• Shipping is available both domestically and internationally.
• Delivery time may vary depending on the destination.
• Customers will receive a tracking number to monitor the status of their shipment.

AUO G215HVN01.3 Packing Details
Package Box :	Quantity	Weight	Box Size (L*W*H)
	7pcs / box	30.9 Kgs (Max.)	602*372*367 mm
