Sharp 800x480 Resolution LVDS Kyocera TN LCD Display with Wide
Viewing Angle and Contrast Ratio
Product Information:
| Brand | Kyocera |
| Model P/N | TCG070WVLPAANN-AN50 |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 800(RGB)×480, WVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 152.4(W)×91.44(H) mm |
| Bezel Opening | 154.4(W)×93.4(H) mm |
| Outline(mm) | 165(W)×104.4(H)×8.5(D) |
| Luminance | 700 (Typ.)(cd/m²) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) |
| Good View at | 12 o'clock |
| Color Depth | 262K 49% NTSC |
| Mass | 195g (Typ.) |
| Refresh Rate | - |
| Treatment | Antiglare |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Work Mode | TN, Normally White, Transmissive |
| Response | 5/25 (Typ.)(Tr/Td) ms |
| Backlight | 2 strings WLED , 70K hours , No Driver |
| Used for | Industrial |
| Touchscreen | Without |
| Signal Type | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
Features:
One of the standout features of this industrial TFT LCD is its wide
operating temperature range, which is -20 to 70 °C. This makes it
suitable for use in harsh environments where temperature
fluctuations are common. Whether you need a screen for an outdoor
kiosk or an industrial control panel, the Kyocera LCD Display can
handle it.
The viewing direction of this display is TN, which means it has a
fast response time and excellent color reproduction. TN screens are
known for their high contrast ratios, and this display is no
exception. It has a contrast ratio of 1000, which means that the
colors on the screen are vibrant and easy to see.
The outline dimension of this industrial TFT LCD is
165(W)×104.4(H)×8.5(D), which means that it is compact and can fit
into tight spaces. Despite its small size, the screen is easy to
read and has a resolution of 800×480 pixels.
The LED backlighting on this display has a lifetime of 70,000
hours, which means that it is energy-efficient and will last for
years. This makes it a cost-effective solution for industrial
applications where screens are often left on for long periods of
time.
If you are looking for an industrial TFT LCD that is reliable,
durable, and energy-efficient, the Kyocera LCD Display is an
excellent choice. As a leading LCD display manufacturer, Kyocera
has a reputation for creating high-quality products that can stand
up to the demands of industrial use.
Applications:
This high-quality display boasts ISO 9241, IEC62341, JEITA CP-3451,
ANSI/AAMI ES60601-1-2, and IEC 60068 certifications, ensuring that
it meets or exceeds industry standards for performance and
reliability. With a minimum order quantity of just one piece and a
supply ability of 500,000 pieces per day, Kyocera is well-equipped
to handle your LCD display needs, no matter the size or scope of
your project.
The TCG070WVLPAANN-AN50 is a 7-inch TN display with an outline
dimension of 165(W)×104.4(H)×8.5(D) and an active area of
152.4(W)×91.44(H) mm. It offers a viewing angle of 80/80/60/80
(RLUD), making it ideal for a wide range of applications. Whether
you need a military LCD display for harsh environments or an
industrial TFT display for manufacturing processes, the
TCG070WVLPAANN-AN50 is up to the task.
Support and Services:
Our technical support team is available to assist with any
questions or issues regarding your Kyocera LCD Display product. Our
services include:
- Remote technical support
- On-site technical support
- Repair and maintenance services
- Product training and education
- Software and firmware updates
- Warranty services
We are committed to providing the highest level of support to
ensure that your Kyocera LCD Display product operates at peak
performance.
Packing and Shipping:
Product Packaging:
- 1 Kyocera LCD Display
- 1 Instruction Manual
Shipping:
- Ships within 1-2 business days
- Expedited shipping available for an additional fee
- International shipping available for an additional fee
